Model number |
JKJ-MFG130-90M |
Resolution |
1280*1024 |
Exposure mode |
Mono Global Shutter |
Frame frequency |
90FPS |
Chip size |
1/2.7 inch |
Pixel size |
4×4 |
port |
Gigabit network interface |
Trigger mode |
Continuous mode, software triggered mode, or external triggered mode |
Adjustable parameter |
Exposure time, digital displacement, gain, white balance, packet delay |
Input/output |
With optocoupler isolation, 1 input, 1 output, extensible |
Lens interface |
C-port |
Transmission interface |
Ethernet interface |
Transmission distance |
100 m no relay transmission |
Power supply requirement |
External 12V / 24V power consumption ≈ 3W |
Working environment |
Temperature: -10~60° C Humidity: 20%~80% |
Storage environment |
Temperature: -20~80℃ Humidity: 20%~80% |
Support protocol |
GigeVision1.2 |
Mechanical dimension |
59.93 x 29 x 29（mm） |
weight |
＜ 90g |
