Model Specification Parameter |
|||||||
Model number |
JKJ-VC2070-8 |
||||||
CPU |
Intel Core 6th /7th i7/i5/i3 Processor |
||||||
Running memory |
16G / 32G / 64G / 128G (capacity can be customized) |
||||||
store |
250G SSD + 1TB HDD (Capacity can be customized) |
||||||
Graphics processor |
Intel UHD Graphics Optional Independent Graphics card (RTX 3070TI / 3090TI) |
||||||
Number of cameras available |
8 CCDS |
||||||
Light source control |
4 channels digital light source brightening module, support visual light source brightness control, maximum power support 120W |
||||||
IO |
Supports 8 programmable IO controls |
||||||
String communication interface |
2 RS232 (can be set to RS422/485) |
||||||
Display interface |
VGA / DVI / HDMI / DP |
||||||
Audio interface |
Line OUT / MIC / Line IN |
||||||
Ethernet interface |
Three Gigabit Ethernet interfaces |
||||||
Camera interface |
8 Gigabit network camera interfaces |
||||||
USB interface |
6 × USB3.0 2 × USB2.0 |
||||||
dongle |
built-in |
||||||
Traditional PCI expansion slot |
Support 2 |
||||||
Power source |
AC100-240V 50/60Hz |
||||||
Typical power consumption |
≤ 380W |
||||||
Operating system |
Genuine Win10 64-bit operating system (optional Win7 / Win10 / WES7 / Linux, 32-bit / 64-bit) |
||||||
Heat dissipation mode |
Intelligent temperature control radiator |
||||||
Size (mm) |
420 × 420 × 175 |
||||||
Adapt to the environment |
Operating temperature: -10~50° C Storage temperature: -20~60° C Humidity: 5~ 90% (no condensation) |
||||||
Product Feature |
High performance multi-core processor |
Supports simultaneous acquisition by multiple IP cameras |
Supports four light sources control |
Supports high-performance GPU graphics processors |
Supports 3D camera deep learning applications |
Supports eight I/O controllers |
Provide rich visual control interface |
Integrated compact design saves installation space |
